Power Handling Co. Ltd

Travel distance： Short, Medium, Long distance

Load capacity(Q)： 1.6 ~ 3.6 t

Related Product

Innovative 3-phase AC technology

Jungheinrich motors in 3-phase AC technology provide increased efficiency with reduced operating costs at the same time:

• Highly efficient with excellent energy management.
• Powerful acceleration even with maximum load.
• Quick direction change without the usual time delay.
• No carbon brushes – the drive motor is maintenance-free.
• 2-year warranty on drive motor.

High performance drive motor and “intelligent” controls (SpeedControl)

Advanced 3-phase AC drive technology and electronic control(SpeedControl) ensure safe and economical operation with adjustment for every application.

• The travel speed is maintained in every travel situation – specially on gradients.
• The ERE series is automatically braked during unintentional roll back on ramps.
• Energy reclamation through regenerative braking on travel speed reduction.
• 2-year warranty on drive motor


Compact construction for every applications

• Utilisation in confined spaces with narrow chassis (700 mm) and short chassis length.
• Safe operation also with heavy loads through robustly designed support arms.
• Low-fatigue operation with ergonomically designed tiller head which has low steering forces.


Flexible application opportunities

Two platform designs (foldable/fixed) allow usage in different applications:

Design 1: Foldable stand-on platform with side support arms.

• Choice between pedestrian and stand-on operation.
• Reduced travel speed (6.0 km/h) with folded in side supports.

Design 2: Fixed stand-on platform with enclosed support guards (optional)

• Exclusively for applications without pedestrian operation.
• Safe standing with side protection.
• Protection for the operator on both sides

Optimum travel characteristics

• Hydraulically sprung cushioned side support wheels – connected via ProTracLink ensure safe and stable operation in all applications.
• Jungheinrich ShockProtect – protection for operator, truck and load through loaded sprung drive. The sprung loaded system reduces vibrations for operator and chassis.


Long operating times
Battery capacities up to 375 Ah ensure long operating times:

• Short version: 2 PzS 230 (250) Ah.
• Long version: 3 PzS 345 (375) Ah.
• Side battery replacementfor fast battery change in multi-shift applications. (optional)

Options:

• Entry rollers.
• Vertical load guard.
• Cold store design.
• Well informed at any time:
  • Information display “CanDis” (optional) with additional operating hour display and service code memory.
  • Activation of truck via PIN through “CanCode” (optional).
  • Further adjustment for drive parameters (optional).

3-phase AC technology

foldable/fixed stand-on platform

Protected operator workplace with fixed stand-on

Jungheinrich CanCode and CanDis (optional)
